Electrocompaniet ECI 6 DX MKII Integrated Amp/DAC/Streamer

The new ECI 6 DX MKII combines a best-in-class feature set with cutting edge audio technology and true Electrocompaniet sound.
This single unit is able to play whichever, wherever and whatever audio source you may have, and makes it sound like music was meant to be sounding.

JPLAY CERTIFIED

Electrocompaniet has officially joined the prestigious JPLAY Certified family! Experience audio perfection as the JPLAY app now integrates seamlessly with all current Electrocompaniet products in the EC Living Line andClassic series.

QOBUZ CONNECT

Electrocompaniet is thrilled to announce the launch of the latest version of its in-house developed popular EC Play app and streaming software. Packed with exciting new features and improvements, this release aims to provide music enthusiasts with an elevated audio experience.
One of the key highlights of the new EC Streaming Engine is support for Qobuz Connect.

ROON READY

With Roon, you’ll rediscover old favorites and find new music you love. Explore the world of music as you listen, precisely tailored to your tastes.

TIDAL CONNECT

TIDAL Connect allows you to stream your favorite music seamlessly from the cloud straight to your connected devices. TIDAL Connect makes it possible for us to deliver the music you want to hear, uninterrupted and without any loss in quality.

BLUETOOTH-ENABLED

The ECI6 DX MKII introduces Bluetooth support in the ECI 6 DX family, enabling you to stream from any phone or tablet to your ECI6 DX MKII.

IMPROVED EC SOFTWARE ENGINE STREAMER

Like it’s predecessor, it has an extremely powerful built-in streamer, flexible and easy to use. It can play directly from music services such as Tidal, Qobuz and Spotify, can be fed music through AirPlay or DLNA, and it can even index and play from your own music collection stored on your network.

IMPROVED CONSTRUCTION

The ECI 6 DX MKII also features the design upgrades introduced with the MKII series, including new front plate design and updated, more rigid chassis.

EC PLAY APP CONTROL

The ECI 6 DX MKII can be operated by the intuitive iOS or Android application, the universal webinterface, or with the straight forward IR remote control.

Designed And Manufactured In Norway.

TECHNICAL SPECIFICATIONS

DIGITAL SECTION:
D/A Converter: 24 bit/192 kHz
Sample Rate Converter: 24 bit/192 kHz
Inputs: SPDIF, 2x Toslink, 1x USB
USB: Asynchronous  Up To 24bit/ 192kHz Supported
SPDIF: 24bit/ 192kHz
Toslink: 24bit/ 96kHz

STREAMER SECTION:
Advanced 802.11 AC WiFi with MIMO
1x Gigabit Ethernet (1000Mbps)
1x USB For External Storage
iOS, Android And Web App

STREAMING SERVICES:
• AirPlay 2 ®
• Spotify ® Connect
• Qobuz ®
• Plays with Audirvāna
• TIDAL ® Connect
• Roon Ready
• JPLAY Certified
• DLNA
• Internet Radio
• Bluetooth streaming from any Bluetooth enabled device

SUPPORTED FORMATS:
All popular formats including: WAV/WAVE, MP3, AAC+, Vorbis, ALAC, FLAC, APE, WMA, up to 192kHZ/24bit, DSD, up to DSD 128 (5.6 MHz)

PREAMPLIFIER SECTION:
Input impedance (Balanced input): 47 kOhms
Maximum input level: 10 Volt RMS
Noise floor (1Vrms, 20 - 20 kHz, balanced): -135 dB
THD + N (1Vrms, 20 - 20 kHz, balanced): <0.004%
Gain (Balanced): 0 dB

AMPLIFIER SECTION:
Output Impedance: < 0,02 Ohm
Frequency response: 1 – 150 kHz
Channel separation: > 120 dB
THD (20 - 20 kHz): < 0.004%
Maximum peak current: >100A
Damping factor 8 ohm load: >350
I Input sensitivity  120W output: 1.3Vrms
Input sensitivity HT  120W output: 1Vrms
Gain HT Input: x36 (31 dB)

RATED OUTPUT POWER:
8 ohms: 2 x 125 W
4 ohms: 2 x 200 W
2 ohms: 2 x 370 W

POWER CONSUMPTION:
110 W
Standby: 1W

DIMENSIONS:
Width: 470 mm / 18.3 inches
Depth (with a speaker terminals): 430 mm / 16,9 inches
Height: 128 mm / 5 inches
Weight: 20,5 Kg / 45 lbs.
